ASUS Prime Z690-P D4-CSM

LGA 1700, Intel Z690H, ATX
2Ratings
Currently out of stock

Product details

The ASUS Prime series motherboards have been developed by experts to fully utilize the potential of Intel's 12th generation processors. With a robust power design, comprehensive cooling solutions, and intelligent tuning options, the Prime Z690-P D4 CSM offers users and PC DIY builders a range of performance tuning options through intuitive software and firmware features. The ASUS Prime Z690-P D4 CSM features a sleek, futuristic case with a black and white finish, space shuttle-inspired design elements, a metallic nameplate, and a PCB cover. The ASUS Corporate Stable Model (CSM) is a commercial program designed to deliver stable and reliable motherboards. We provide product lifecycle support of up to 36 months and a 6-month advance notice for the end of the product lifecycle, giving businesses ample time to prepare for product transitions.

Key specifications

Processor family
Core i5, Core i7, Core i9
Memory type
DDR4-RAM
Number of memory modules (RAM)
4 x
Internal connection options
S-ATA III (4x)
Mainboard features
Front panel audio connector
Item number
17529997

General information

Manufacturer
ASUS
Category
Motherboards
Manufacturer no.
90MB18P0-M0EAYC
Release date
14/7/2022

Motherboard properties

Form factor
ATX
Socket
LGA 1700
Chipset
Intel Z690H
Mainboard features
Front panel audio connector
Operating system compatibility
Windows, Windows 10
BIOS type
UEFI AMI

Processor

Processor family
Core i5, Core i7, Core i9

Memory

Memory form factor
DIMM
Number of memory modules (RAM)
4 x
Max. memory (RAM)
128 GB
Memory chip
DDR4 RAM
Max. RAM OC
5333 MHz
Supported memory speed
2400 MHz, 2666 MHz, 2800 MHz, 2933 MHz, 3000 MHz, 3200 MHz, 4000 MHz
Memory type
DDR4-RAM
RAM buffer
Unbuffered

Graphics properties

Video connections
DisplayPort (1x), HDMI (2x)
Video connection version
HDMI 2.1

Network

Network connections
RJ45 (1x)
Ethernet controller brand
Intel
Ethernet controller
Gigabit Ethernet
Max. port speed
2.50 Gbit/s

Audio

Chip
High Definition Audio
Audio channel
7.1 Channel
Audio Connections
Headphone output (5x)

Data storage

RAID configuration
0, 1, 10, 5

Internal interfaces

Internal connection options
S-ATA III (4x)
Expansion slot
PCI Express x1 (Gen 3) (1x), PCI Express x16 (Gen 3) (1x)
PCI express version (max.)
4
Number of fan connector
3

Further connections

USB ports
USB-A
Exact USB ports
USB-A 3.2 Gen 1 (2x), USB-C 3.2 Gen 2 (1x)

Power supply

Power connectors
20+8 pin ATX, 24-pin EATX

Sustainability

Manufacturer commitment
RE100, SBTi

Voluntary climate contribution

Manufacturer compensation
According to RE100, the manufacturer ASUS fully compensates for its energy consumption, leading to a reduction in emissions.
CO₂-Emission
Climate contribution

Scope of delivery

Scope of delivery
Sata Cables

Product dimensions

Length
234 mm
Width
305 mm
Height
73 mm
Weight
634 g

Package dimensions

Length
34 cm
Width
28 cm
Height
7 cm
Weight
1.74 kg
