Intel NUC NUC8i7BEH2 - Bean Canyon

Intel Core i7-8559U
Currently out of stock

Product details

The built-in Intel Core processor of the eighth generation is based, like its predecessor, on the energy-efficient 14nm architecture, which does not overheat even under full load, but delivers more performance while maintaining the same power consumption. The main innovations include various performance optimizations and an increased number of physical and virtual cores, which provide a significant boost in performance and smooth multitasking. The graphics solution allows for many features that were previously reserved for dedicated graphics cards – from video editing to gaming and 4K video playback. Thanks to Turbo Boost 2.0, it can dynamically adjust its clock speed to find the optimal balance between energy consumption and performance.

Key specifications

Number of processor cores
4 -Core
Graphics card model
Iris Plus Graphics 655
Internal connection options
M.2 (1x)S-ATA III (1x)
Network connections
RJ45 (1x)
Video connections
HDMI (1x)
Memory type
DDR4-RAM
USB ports
Thunderbolt 3USB-A
Item number
9877627

General information

Manufacturer
Intel
Category
Barebones
Manufacturer no.
BOXNUC8I7BEH2
Release date
9/10/2018
External links

Barebone properties

Design
Small Form

Processor

Processor type
Intel Core i7-8559U
Clock frequency
2.70 GHz
Number of processors
1 x
Number of processor cores
4 -Core
Number of threads
8
Socket
BGA 1528
Max. turbo clock rate
4.50 GHz
Max. TDP
28 W
Processor properties
Intel Virtualisation Technology (VT-x)

Memory

Memory type
DDR4-RAM
Memory form factor
SO-DIMM
Number of pins
260 x
Memory chip compatibility
DDR4-2400
Memory Slots available
2
Max. memory slots
2
Max. RAM
32 GB
Memory voltage
1.20 V

Graphics card properties

Graphics card model
Iris Plus Graphics 655
Max. connected monitors
3 x

Internal connections

Internal connection options
M.2 (1x)S-ATA III (1x)
RAID configuration
01
"Number of 2.5"" drive slots"
1 x

External connections

USB ports
Thunderbolt 3USB-A
Exact USB ports
Thunderbolt 3 (1x)USB-A 3.1 Gen 1 (4x)

Network

Network connections
RJ45 (1x)
Max. port speed
1000 Mbit/s

Wireless transmission

Connectivity
BluetoothWLAN
Wi-Fi standard
Wi-Fi 1 / 802.11bWi-Fi 2 / 802.11aWi-Fi 3 / 802.11gWi-Fi 4 / 802.11nWi-Fi 5 / 802.11ac
Bluetooth version
5.0

Video connections

Video connections
HDMI (1x)

Audio connections

Audio outputs
3.5mm jack (1x)

Card reader properties

Memory card type
microSDXC

Power supply properties

Power
65 W

Voluntary climate contribution

CO₂-Emission
Climate contribution

Scope of delivery

Scope of delivery
PC Barebone

Product dimensions

Width
117 mm
Length
112 mm
Height
51 mm

Package dimensions

Length
15.50 cm
Width
12 cm
Height
13 cm
Weight
1.29 kg
