Standard, max. total power consumption 50 VA, max. rated load of all drives 24 W, fuse T4A, inrush current per actuator max. 500 mA, integrated standard-compliant strain relief, screwless terminal technology for connection cross-sections up to max. 1.5 mm², two separate lowering channels for control via external timer signal, protection class IP 20, protection class II, dimensions 90 x 327 x 50 mm, housing ABS light gray, cover transparent.

Installation note according to § 13 NAV.

Please note that devices with a connection value of 230 V will be delivered with either a protective contact plug or a fixed connection (without plug) depending on the power rating. If the device has a fixed connection, a qualified technician must be commissioned for the installation. All devices with a connection value of 400 V and above must be operated via a suitable high-voltage connection and may only be connected by a qualified electrician. For devices with a rated power of more than 12 kW, approval from your network operator is required. Please contact the network operator or an installation company registered in the network operator's installer directory before installation. Such an installation company will assist you in obtaining the necessary approval from the respective network operator.
