Satel APS-412

Price in EUR including VAT
Ratings
BrandMore from Satel
Delivered between Thu, 24/7 and Sat, 26/7
free shipping

Product details

Satel APS-412 Buffer Power Supply 230V/4A/12VDC, DIN Rail

The switching power supply is designed to power 12 V devices. It is equipped with a connection for SATEL devices. It can be mounted in a SATEL enclosure or on a DIN rail.

  • EN50131-6 Grade 2 certified
  • 12 V DC switching power supply with high efficiency, does not require a mains transformer
  • total power output of the power supply: 4 A
  • protection against short circuits and overload
  • possible connection of a lead-gel battery
  • selectable value for battery charging current
  • battery charging system with current adjustment
  • deep discharge protection
  • 3 open-collector outputs for signaling faults
  • optical signaling of the status of mains power supply, battery, and overload
  • acoustic signaling of faults
  • connection of SATEL devices
  • possible mounting on a DIN rail (35 mm) as well as in enclosures OPU-3 P, OPU-4 P, and OPU-4 PW.

Key specifications

Scope of application
Network cabinet
Item number
15684444

General information

Manufacturer
Satel
Category
UPS
Manufacturer no.
APS-412
Release date
16/4/2021

UPS functions

UPS protection functions
Overvoltage protection

Application range

Scope of application
Network cabinet

Mains supply properties

input voltage
10.5 V
output voltage
12 V
Max. input current
4 A

Operating conditions

Operating temperature
-10 - 55 °C

Battery properties

Battery category
Device batteries
Battery
Rechargeable battery
Battery type
Li-ion
Battery size
Device specific
Number of cells
1 x
Battery weight per cell
306 g
Voltage
10.50 V
Capacity
7 Ah

Origin

Country of origin
China

Voluntary climate contribution

CO₂-Emission
Climate contribution

Scope of delivery

Items per sales unit
1 x

Product dimensions

Height
122 mm
Weight
0.31 kg
Width
77 mm
Length
59 mm

Package dimensions

Length
17.30 cm
Width
10.90 cm
Height
8 cm
Weight
418 g

14-day cancellation right
30-day right of return
24 Months statutory warranty
