The Wi-Fi 6 functions OFDMA and MU-MIMO for upload and download increase the capacity of the WLAN network significantly compared to Wi-Fi 5 (802.11ac) in high-density environments, allowing more devices to connect simultaneously. The Omada Wi-Fi 6 access points benefit from Wi-Fi 6 - 802.11ax technologies such as 1024 QAM and improved OFDM WLAN symbols. These innovations enable speeds of up to a combined 3550 Mbps, with 2404 Mbps in the 5 GHz band and 1148 Mbps in the 2.4 GHz band. With four simultaneous data streams, throughput increases significantly, especially when multiple devices are using Wi-Fi at the same time, enabling more applications.
Wi-Fi standard | Wi-Fi 6 / 802.11ax |
Wi-Fi frequency band | Dual band |
PoE Standard | 802.3af (PoE), 802.3at (PoE+) |
Operating modes | Access point |
Area of application | Business, Indoor |
Number of RJ45/LAN ports | 1 |
Max. port speed | 2500 Mbit/s |
Item number | 42304882 |
Manufacturer | TP-Link |
Category | Access points |
Manufacturer no. | EAP660 HD |
Release date | 20/1/2021 |
Operating modes | Access point |
Max. number of clients | 1000 x |
Number of antennas | 8 x |
Antenna gain | 5 dB |
Number of RJ45/LAN ports | 1 |
Max. port speed | 2500 Mbit/s |
Access Point Functions | Mesh capable, PoE capable |
Wi-Fi standard | Wi-Fi 6 / 802.11ax |
5 GHz transfer rate | 2402 Mbit/s |
2.4 GHz transfer rate | 1148 Mbit/s |
Wi-Fi frequency band | Dual band |
Wi-Fi encryption | WEP, WPA-Enterprise, WPA-PSK, WPA2-Enterprise, WPA2-PSK, WPA3-Enterprise |
Area of application | Business, Indoor |
Installation place | Ceiling, Wall |
Power supply | PoE |
PoE Standard | 802.3af (PoE), 802.3at (PoE+) |
Power consumption | 18.50 W |
Country of origin | China |
CO₂-Emission | |
Climate contribution |
Scope of delivery | 1 x power supply, 1x EAP660 HD, 1x wall or ceiling mount |
Length | 24.30 cm |
Width | 24.30 cm |
Height | 6.40 cm |
Weight | 1500 g |
Length | 28 cm |
Width | 25.50 cm |
Height | 9 cm |
Weight | 1.58 kg |
