Hikmicro M20W thermal imaging camera -20 to +550°C 256 x 192 pixels 25Hz WiFi, touchscreen
Only 4 pieces in stock at supplier
Product details
The HIKMICRO M20W thermal imaging camera is a highly advanced device designed for precise industrial analysis. With a temperature measurement range of -20 °C to +550 °C and a resolution of 256 x 192 pixels, this handheld thermal camera offers excellent image quality and high temperature accuracy. The manually focusable VOx detector provides a rapid thermal sensitivity of under 40 mK, enabling the detection of even the smallest temperature differences. The camera features a robust, industrial-grade design and meets the IP54 protection rating, making it suitable for use in demanding environments. Wi-Fi connectivity allows for easy image transfer and real-time reporting, while the long battery life ensures continuous use. The intuitive operation is facilitated by a touchscreen that enables user-friendly navigation through various imaging modes and functions.
- Manually focusable VOx detector for precise temperature measurements
- Real-time image transmission via Wi-Fi for immediate analysis
- Robust design with IP54 protection for use in harsh environments
- Long battery life for uninterrupted continuous use.
Image resolution | 256 x 192 pixels |
Temperature measuring range min. | -20 °C |
Temperature measuring range max. | 550 °C |
Thermal imaging camera type | Hand-held thermal imaging camera |
Item number | 32832201 |
Manufacturer | Hikmicro |
Category | Thermal imaging cameras |
Manufacturer no. | HM-TP22-3AQF/W-M20W |
Release date | 8/4/2023 |
Thermal imaging camera type | Hand-held thermal imaging camera |
Temperature measuring range min. | -20 °C |
Temperature measuring range max. | 550 °C |
Measurement accuracy | 40 °C |
Thermal sensitivity (NETD) | 40 mK |
Horizontal field of view | 50° |
Vertical field of view | 37.20° |
Focus type | Fixed |
Refresh rate | 25 Hz |
Image sensor resolution | 49152 Pixels |
Image resolution | 256 x 192 pixels |
Interfaces / communication module | Bluetooth, USB, Wi-Fi |
USB connector type | USB-C |
Protection type (IP code) | IP54 |
Power supply | Rechargeable battery operated |
Country of origin | China |
CO₂-Emission | |
Climate contribution |
Scope of delivery | 1 charger, 1 HIKMICRO M20W thermal imaging camera, 1 piece 64GB Micro SD card, 1 piece wrist strap and hard case, 2 rechargeable batteries |
Length | 24.40 cm |
Width | 10 cm |
Height | 10.40 cm |
Weight | 660 g |
Length | 44 cm |
Width | 35 cm |
Height | 22 cm |
Weight | 3.79 kg |
