Legrand Dx3 FI/LS switch C16A 1P+N 411061 6Ka 30Ma A 411061
More than 10 pieces in stock at supplier
Product details
DX3 RCD/MCB, C-curve, 16A, single pole with switched neutral, 6kA, 30mA, Type A, 230VAC, 2 modular units, 411061.
Optimal protection: The DX3 Type A RCD/MCB is the perfect solution to make your electrical installations safer. The switch provides protection against alternating and pulsating DC fault currents.
Residual current circuit breaker: The instantaneous Type A residual current circuit breaker immediately detects even the smallest deviations, thus protecting your circuit by instantly disconnecting your installation.
Tripping indicator: The easily visible tripping indicator provides you with immediate feedback on the switching status. It distinguishes between yellow (fault current or test button tripping) and white (short circuit or manual tripping).
Circuit breaker: The C-curve circuit breaker keeps your circuit flowing steadily, ensuring lasting safety in various applications by minimizing disturbances.
User-friendly: The RCD/MCB is user-friendly, thanks to the clear red/green switching position indicator on the switch lever (lockable) and the clearly readable labeling window.
Installation: You can easily install the RCD/MCB on a DIN rail EN 6715 using a snap-on quick fastening system and add additional auxiliary devices as needed.
Technical details: 25A short-circuit withstand, 230V rated voltage, 50Hz rated frequency, 30mA rated residual current, 16A rated current, 2 modular dimensions (17.5mm).
Circuit breaker type | Miniature circuit-breaker/residual current circuit-breaker combination |
Mounting type | Flush-mounted |
number of poles | 2 |
Length | 70 mm |
Width | 36 mm |
Item number | 22654293 |
Manufacturer | Legrand |
Category | Residual-current device |
Manufacturer No. | 411061 |
Release date | 13/10/2022 |
Colour | Grey |
Exact colour description | Grey |
Circuit breaker type | Miniature circuit-breaker/residual current circuit-breaker combination |
Mounting type | Flush-mounted |
Mounting type | Engagement |
number of poles | 2 |
Tripping characteristic | C |
Rated current | 16 A |
Rated voltage | 230 V |
voltage type | AC |
Residual current (rated differential current) | 0.03 A |
Protection type (IP code) | IP20 |
Country of origin | China |
Manufacturer commitment | SBTi |
CO₂ emissions | 12,52 kg |
Climate contribution | EUR 0,31 |
Items per sales unit | 1 pcs. |
Length | 70 mm |
Width | 36 mm |
Height | 44 mm |
Weight | 238 g |
Product Safety |
Length | 11.10 cm |
Width | 9 cm |
Height | 4.20 cm |
Weight | 237 g |
