Shelly Qubino Wave Shutter

Switch actuator
Price in EUR including VAT
Delivered between Sat, 9/8 and Wed, 13/8
More than 10 pieces in stock at supplier
free shipping

Product details

Professional 3-channel DIN rail Z-Wave smart switch with dry contacts. Suitable for home and facility automation with remote control. DIN-rail mountable inside a breaker box. Enhanced safety features. 3 outputs, 16 A each. Total device maximum of 48 A. DIN-rail mountable. Dry contacts. Extremely low power consumption: < 0.3 W. Z-Wave frequency band: 868.4 MHz (CEPT countries). Latest technology: Z-Wave 800 Series. Automatic set-up with SmartStart. Security 2 Authenticated for the highest level of security. Over-the-air firmware updates. Works with Z-Wave-certified gateways and over 4,000 Z-Wave devices.

Key specifications

Actuator type
Switch actuator
mounting style
Top-hat rail
communicating
Cable
Items per sales unit
1 x
Smart Home Systems
Amazon Alexa
Smart Home Protocol
Z-wave
Item number
46984542

General information

Manufacturer
Shelly
Category
Actuator
Manufacturer no.
Shelly-Qubino-Wave-Pro3
Release date
2/7/2024

Colour

Colour
Black
Exact colour description
Black

Material

Material group
Plastic
Material
Plastic case

Actuator properties

Actuator type
Switch actuator
Max. Switching capacity
0.03 W
rated current
16 A
Operating voltage
230 V
Number of switching outputs
3 x
mounting style
Top-hat rail

Smart home features

Smart Home
Compatible
Smart Home Systems
Amazon Alexa
Smart Home Protocol
Z-wave
communicating
Cable
Radio frequency
868400000 Hz
Requires Smart Home Hub
Yes

Origin

Country of origin
China

Voluntary climate contribution

CO₂-Emission
Climate contribution

Scope of delivery

Items per sales unit
1 x

Product dimensions

Length
69 mm
Width
53 mm
Height
94 mm
Weight
150 g

Package dimensions

Length
9.80 cm
Width
8.10 cm
Height
6.20 cm
Weight
177 g
