Best Theben products in the Timers category
On this page you'll find a ranking of the best Theben products in this category. To give you a quick overview, we've already ranked the most important information about the products for you.
1. Theben ELPA 1
Theben staircase time switch ELPA 1
Manufacturer: Theben
Designation: Staircase time switch 1S, 0.5-20 min
Type: ELPA 1
Function: Electronic with multifunction
Mounting type: DIN rail
Width in pitch units: 1
Installation depth: 60 mm
Number of contacts as NO contacts: 1
Control voltage 1: 220-240 V
Control voltage type 1: AC
Frequency of control voltage 1: 50-60 Hz
Control voltage 2: 8-240 V
Control voltage type 2: AC/DC
Frequency of control voltage 2: 50-60 Hz
Rated switching current: 16 A
Max. switching current (cos phi: 0.6): 16 A
Release delay: 0.5-20 min
Push-button glow lamp current: 150 mA
Circuit type: 3- and 4-wire circuit
Switch-off pre-warning: Flickering
Current surge function selectable: Yes
Post-switching: Can be switched on + continuous light + time extension
Supply voltage: 220-240 V
Supply voltage type: AC
Max. bulb load: 3600 W
Incandescent lamp load: 3600 W
Max. fluorescent lamp load: 3600 VA
Max. fluorescent lamp load (duo circuit): 3600 VA
Max. fluorescent lamp load (parallel compensated): 1200 VA
Theben staircase lighting timer switch ELPA 1 features a row-mounted design with 10 functions, a width of 1 TE, switchable options, and a switch-off pre-warner (DIN 18015-2). It has a long-time range of 60 min, supports 3- and 4-wire connections, and includes a push-button input with electronic overload protection. An additional push-button input is galvanically isolated for intercom systems AC/DC 8-240 V. It also features an LED display.
2. Theben TR 030 top3 UP
The digital timer TR 030 top3 UP from Theben is an advanced solution for the timed control of electrical devices. It is designed for flush mounting and offers a weekly program that allows for flexible adjustments to individual schedules. Programming can be conveniently done via an app, ensuring user-friendly operation. The timer supports secure transmission of time control programs through the optional Bluetooth Low Energy interface OBELISK top3, which provides maximum tamper protection. This feature ensures that programs can only be transmitted when the Bluetooth adapter is plugged into the timer. With a maximum LED power of 600 watts and an inrush current of up to 800 amperes, the timer is versatile and suitable for both indoor and outdoor applications. The integrated power reserve and automatic switching to summer and winter time provide additional convenience.
- App programming for easy handling
- Maximum tamper protection through Bluetooth OBELISK top3
- Compatible with smart home systems like Apple Home and Google Assistant
- Random generator for added security
- Energy efficient with only 0.4 watts standby power.
3. Theben TR 636 top2
The Theben TR 636 top2 is a digital timer designed for a variety of applications. It features a user-friendly text-based interface and a backlit display that simplifies programming and usage. With a wall-mounted installation type and a compact front frame of 72x72 mm, it is ideal for use in various environments. The timer enables precise control of electrical devices through its extensive programming options, including daily and weekly programs as well as special functions like holiday and pulse programs. With a battery life of up to 10 years and automatic summer/winter time adjustment, it ensures reliable and low-maintenance operation. The TR 636 top2 offers flexibility and adaptability for individual needs with 84 memory slots and the option for pre-switching.
- Two channels for independent control of devices
- 84 memory slots for individual programming
- Automatic summer/winter time adjustment
- Random programs to simulate presence
- Text-based interface for easy handling.
4. Theben SUL 188 g
The Theben SUL 188 g is an analog timer designed for rail mounting. It offers a backup time of three days and allows for easy programming via a 24-hour segment program. With a minimum switching time of 30 minutes, this model is ideal for applications requiring precise control of electrical devices. The timer is intended for mounting on a DIN rail and features a robust construction that meets the demands of daily use. The SUL 188 g is a reliable solution for automating lighting and other electrical devices in residential and commercial spaces.
- Easy programming via 24-hour segment program
- Robust construction for daily use
- Suitable for mounting on DIN rails.
5. Theben TR 642 top2 RC
The Theben TR 642 top2 RC is a digital timer designed for precise control of electrical devices. It offers a variety of features that allow for flexible programming and customization to meet individual needs. With the ability to synchronize time via an external DCF or GPS antenna, this timer is particularly suitable for applications that require accurate time measurement. The TR 642 top2 RC supports both annual and astronomical programs, meaning it can automatically calculate sunrise and sunset times. This is especially useful for controlling lighting systems or other devices that depend on daylight conditions. The integrated memory card allows for easy PC programming, while extensive features such as holiday programs and random programs provide additional flexibility. With a battery life of up to six years and a variety of switching cycles, the TR 642 top2 RC is a reliable choice for time-controlled management of electrical devices.
- 2-channel annual timer with extensive annual clock functions
- Astronomical switching function for automatic calculation of sunrise and sunset times
- Interface for OBELISK top2 memory card for PC programming
- Integrated operating hour counter and external push-button/switch inputs
- Random programs and holiday program for additional flexibility.
6. Theben SYN 269 h
Supply voltage = 230 V ac
Type = Analog
Number of channels = 1
Time unit = hours, minutes, seconds
Switching interval = 20 min
Connection type = Screw mounting
Contact arrangement = 1-pole changeover switch
height = 104mm
Depth = 69mm
SYN 269 h - Analog time switch. SYN 269 h - Analog timer switch with daily or weekly program. Features and benefits. 1-channelWithout power reserveSynchronized with power cordSwitching preselectionDurable on/off switchSimple summer/winter time correction- Time can be changed clockwise or counterclockwise32 plungers includedShortest switching time: 20 min. or 2 hoursTime display pointerSwitching status indicatorScrew terminalsFront panel/wall installation.
7. Theben TR 648 top2 RC KNX
The Theben TR 648 top2 RC KNX is a digital timer specifically designed for use in modern smart home systems. It offers a variety of features that enable precise control of electrical devices. Equipped with a yearly and astro program, the timer can automatically respond to varying light conditions and holidays. Programming is conveniently done via the KNX bus or using an OBELISK top2 memory card, which allows for PC programming. The timer also supports time synchronization through the connection of an external DCF or GPS antenna, ensuring accurate time measurement. The TR 648 top2 RC KNX is designed for mounting on a DIN rail and provides a user-friendly interface for easy integration into existing systems.
- Yearly and astro program for flexible time control
- Programming options via KNX bus or OBELISK top2 memory card
- Time synchronization through external DCF or GPS antenna
- Extensive features such as pulse program, cycle program, and holiday program
- Integrated operating hour counter and PIN coding for added security.
8. Theben 9070367 Diode module
Theben diode module 9070367 (VE2) Manufacturer: Theben Designation: Diode module Type: 9070367 (VE2) Function: RC element With LED display: no Theben diode module 9070367 (VE2): further details Diode module for roller shutter push-buttons as well as push-buttons for LUXOR special functions. , EAN: 4003468903605.
9. Theben eltimo 020 As
The eltimo 020 As from Theben is a digital timer that allows for precise control of electrical devices. It features an Astro program that automatically adjusts switching times to sunrise and sunset. This function is particularly useful for automating lighting and other outdoor devices. The timer can also be programmed via an app when using the optional Bluetooth Low Energy OBELISK top3, providing user-friendly and flexible handling. Operation is done through intuitive buttons that allow for easy programming of switching times and weekdays. With a maximum current of 16 Amperes and a rated voltage of 230 Volts, the eltimo 020 As is suitable for a wide range of applications. The automatic switch between summer and winter time ensures that the programmed times are always accurate.
- Astro program for automatic adjustment of switching times to sunrise and sunset
- App programming via optional Bluetooth OBELISK top3
- Maximum manipulation security through secured program transfer
- Easy operation with buttons for program functions and switching times
- Automatic summer/winter time switch for precise time control.
10. Theben SYN 160 a
Analogue time switch
1 channel
Daily program
Without power reserve
96 switching segments
Synchronised with mains
Shortest switching time: 15 minutes
Screw terminals
Manual switch with 3 positions: Permanent ON/AUTO/continuous OFF.
