Vertiv Liebert GXT5
5 VA, 5000 W, Online double converter UPSPrice in EUR including VAT
Delivered between Tue, 4/11 and Tue, 25/11
free shipping
Output power capacity
Product details
The connection and commissioning of a UPS with more than 3.5 kVA must be clarified in advance with the local electricity provider in Switzerland. The connection must be carried out by an electrician.
Operating time at full load | 7 min |
Model | 19" rack |
Scope of application | Server room |
Plug type | IEC 320 |
Item number | 40853143 |
Manufacturer | Vertiv |
Category | UPS |
Manufacturer no. | GXT5-5000IRT5UXLN |
Release date | 13/12/2023 |
UPS type | Online double converter UPS |
Power output | 5000 W |
Output power capacity | 5 VA |
Model | 19" rack |
Rack Unit | 5U |
shaft type | Sine wave |
UPS protection functions | Overvoltage protection, Undervoltage protection |
Scope of application | Server room |
Plug type | IEC 320 |
Connections | RS-232, RS-485 |
USB ports | USB-A |
Network connections | RJ45 (1x) |
Data ports | RS232C in (1x) |
Electrical safety | Due to the high power, this device requires a socket outlet fused with 16 amperes (type 23). If no suitable socket is available, the conversion must be carried out by an authorised installer. |
input voltage | 176 - 288 V |
output voltage | 200 - 240 V |
Max. input current | 16 A |
Input frequency | 40 / 70 Hz |
Output frequency | 50 Hz |
overvoltage protection | 600 J |
Efficiency full load | 94 % |
Efficiency battery operation | 94 % |
Maximum operating temperature | 40 °C |
Operating temperature | 0 - 40 °C |
Operating humidity | 0 - 95% |
Max. noise level | 55 dB |
Protection type (IP code) | IP20 |
Battery category | Industry battery |
Battery | Rechargeable battery |
Battery type | Li-ion |
Number of cells | 16 x |
Voltage | 12 V |
Capacity | 9 Ah |
Charging time | 5 h |
Operating time at full load | 7 min |
Operating time at half load | 18.50 min |
Country of origin | China |
CO₂-Emission | |
Climate contribution |
Scope of delivery | Input power cable, Output power cable, Quick installation guide, USB cable |
Items per sales unit | 1 x |
Height | 217 mm |
Weight | 70.80 kg |
Width | 430 mm |
Length | 630 mm |
Length | 40 cm |
Width | 33 cm |
Height | 24 cm |
Weight | 20 kg |
