Best selling Network switches from Roline
On this page you’ll find a ranking of the best Network switches from Roline. To give you a quick overview, we’ve added the most important product details. This page always stays fresh and updates automatically.
1. Roline Gigabit Ethernet Switch
This product is compact and therefore ideal for SOHO users with limited space to enhance their network connection.
2. Roline Fast Ethernet Switch
The Roline Fast Ethernet Switch is a compact and powerful solution for network connectivity in desktop environments. With eight RJ45 ports, this unmanaged switch enables simple and efficient networking of devices with a maximum network speed of 100 Mbps. The metal housing ensures durability and stability, while the pocket-sized design allows for flexible placement. The switch supports Auto-MDI/MDI-X and Auto-Negotiation, simplifying setup and operation. Thanks to the Store-and-Forward technology and Non-Blocking architecture, reliable data transmission is guaranteed, providing high performance even under full traffic conditions. Power can be supplied via a USB port or an external power adapter, offering additional flexibility for installation.
- Unmanaged switch for easy installation and use
- Supports Auto-MDI/MDI-X and Auto-Negotiation for flexible connections
- Store-and-Forward technology for reliable data transmission
- Non-Blocking architecture for high performance under full traffic
- Compact pocket-sized design for flexible placement.
3. Roline Industrial Switch 5x RJ-45, unmanaged
The ROLINE Industrial Switch is an unmanaged Fast Ethernet Switch specifically designed for use in industrial environments. With five 10/100Base-T ports, it provides a reliable network connection and is ideal for applications that require a robust and stable network architecture. The switch can be easily mounted on a DIN rail, making it particularly flexible in installation. It supports an operating voltage of +7 to +30 VDC and is designed for operating temperatures ranging from -10 °C to +70 °C, allowing it to be used in demanding environments. Power supply is provided via a terminal block or a DC barrel connector, offering additional installation options. The ROLINE Industrial Switch is an excellent choice for companies seeking a cost-effective and high-performance solution for their networking needs.
- DIN rail mounting for flexible installation
- Operating temperature range of -10 °C to +70 °C
- DC input via terminal block or DC barrel connector
- Robust design for industrial applications
- Unmanaged switch for easy handling.
4. Roline Gigabit PoE extension, 2 port
2-Port Gigabit PoE Extender designed to extend the connection distance by an additional 100 m at both ends over a Cat-5e cable or better. Suitable for covering longer distances by cascading multiple PoE extenders in a network. No additional power supply is required. LAN cables are used to power IEEE 802.3at compliant network devices. It features PoE detection to check whether the network device receiving power is IEEE 802.3at compliant or if only data is being transmitted over the LAN cable. No special network cables are required.
Input: 1x 10/100/1000 ports for data and power. Output: 1x 10/100/1000 ports for data and power. By adding PoE devices, it is possible to use an existing standard Cat-5e or Cat-6 Ethernet cable without needing a new outlet for power and data. Supports PoE IEEE 802.3af/at. Powered via PoE - consumes about 2W. Weight: 100 g. Dimensions (H x W x D): 20 x 32 x 123 mm. Metal housing - wall mounting possible.
Contents: Extender.
5. Roline Industry Converter Ethernet
Palmsize switch in proven ROLINE quality. Easy to install (plug and play), no configuration effort required. Supports 10 and 100 MBit/s (auto-negotiation) on each port. Supports half and full duplex on each port. Supports auto-MDI/MDI-X detection on each port. Supplied with: switch, power supply, manual.
Key features:
- Management features
- Switch type: unmanaged network switch
- Ports and interfaces: number of base switching RJ-45 Ethernet ports: 5
- Network full duplex: yes
- Data transmission: MAC address table automatic learning, automatic update
- Max. data transmission rate: 0.1 Gbit/s
- Protocols: data link protocols fast Ethernet
- Design: stackable: no
- Energy: power consumption (typical): 4.2 W
- Power over Ethernet (PoE) support: no
Further specifications:
- Data transmission rate: 10 Mbit/s
- Dimensions (WxDxH): 140 x 85 x 30 mm
- Transmission technology: wired
- Power supply: external
- Technical features: auto-MDI/MDI-X management functions.
6. Roline Gigabit Eth. Switch
The ROLINE Pocket Gigabit Ethernet Switch is a compact and powerful solution for small networks. With four 10/100/1000 Mbps ports, this unmanaged switch provides an easy way to connect devices in a local network. The auto-negotiation feature ensures that the ports automatically negotiate the optimal connection speed, while the shielded RJ-45 ports guarantee reliable data transmission. The switch supports full-duplex operation for a maximum bandwidth of 1000 Mbps and can store up to 1,000 MAC addresses. Thanks to the store-and-forward switching with a data buffer of 430 KB, efficient data processing is ensured. The space-saving black metal housing makes the switch ideal for use on a desk or in tight spaces. Power is supplied via an external power adapter or a USB connection, providing additional flexibility.
- Auto-negotiation for optimal connection speed
- Supports jumbo frames up to 9k for improved data transmission
- Store-and-forward switching with a 430 KB data buffer
- Flow control according to IEEE 802.3x in full-duplex mode
- Space-saving design with a robust metal housing.
7. Roline gigabit switch
Managed 5-port Gigabit network switch for use in an industrial environment, including an additional SFP port.
8. Roline Ind. SNMP 10x GbE switch, 2x SFP web-based, 250W
The Roline Ind. SNMP 10x GbE Switch is a powerful DIN-Rail switch specifically designed for industrial use. With 10 ports, including 8 RJ45 ports and 2 SFP ports, this switch offers gigabit bandwidth suitable for demanding network environments. It supports PoE+ according to the IEEE 802.3bt standard with a PoE budget of 240W, making it ideal for powering connected devices. The switch is equipped with advanced Layer 2 features and provides a variety of security and management tools that enable efficient network management. The operating temperature range of -30°C to +70°C and the over/under voltage protection ensure reliable performance in harsh environments. With a DIN rail mount and a robust, fanless metal housing, this switch is both practical and durable.
- Supports PoE+ with a budget of 240W for powering connected devices
- Advanced Layer 2 features for improved network management
- Operating temperature range of -30°C to +70°C for industrial use
- Web, SNMP, and Telnet management for flexible configuration
- Robust, fanless metal housing for long-lasting durability.
9. Roline Gigabit Ethernet Ind. switch, 6x
5-Port Gigabit Network Switch for use in industrial environments - including an additional SFP port! Gigabit Ethernet switch with 5x 10/100/1000Base-T ports and one SFP slot. Supports auto-negotiation, auto-MDI/MDI-X. Designed for industrial applications. Supports jumbo frames. Can be mounted on DIN rails or with a mounting plate. Operating voltage: +7 to +57 VDC. DC input via terminal block or DC barrel connector (6.3 mm/2.0 mm).
10. Roline Industrial Switch 6x RJ-45, 2x SC, unmanaged
Fast Ethernet switch with 8 ports - 6x 10/100Base-T and 2x 100Base-FX multimode. Designed for use in industrial environments with DIN rail mounting. Operating voltage: +7 to +30 VDC, 6.5 W (max). Operating temperature range: -20 ºC to +70 ºC. Input DC via terminal block or DC hollow plug (6.3 mm/2.0 mm). A suitable power supply is recommended.
Technical Data:
- Manufacturer: ROLINE
- Part No: 21.13.1154
- Product Group: Network Switches
- Product Type: Switch
- LAN (Mbps): 10/100 Fast Ethernet
- RJ-45 Ports: 6
- Fiber Ports: 2
- Type of Fiber Ports: 100Base-FX multimode, SC
- Fan: No
- Network Standard: Fast Ethernet
- Switch Type: Store-and-forward
- Switching Fabric Type: Non-blocking
- Manageable: No
- Full duplex: Yes
- Autonegotiation: Yes
- Stackable: No
- Technical Features: -20 ºC to +70 ºC
- Dimensions (HxWxD): 106 x 40 x 140 mm
- Power Supply: External
- Power Consumption: Max. 7.3 W
- Gross weight: 0.665 kg including packaging.
