Product strengths:
Safety: locking of the puller arms on the bearing with the central nut. The extractor cannot slide off the bearing. Spindle with safety head. A pin shears off if the permissible tightening torque is exceeded. Supplied with 2 spare pins. With locking screw U.20-12. The locking screw protects the spindle when a rod is used to prevent the puller from turning. Suitable puller: slide hammer U.2.

Technical data:
Min.-max. C [mm]: 25 - 260
L x W x H [mm]: 125 x 325 x 370
Max. T [mm]: 220
Hexagon [mm]: 24
Pulling arms: U.20BSE4
Tons [t]: 7
Screws: U.20-B1S
Screws [mm]: 24
T [kN]: 70
Weight [kg]: 4.3

Extent of warranty: E.
