This M12 sensor cable by Delock is designed for direct current applications. The L-coded version features 5 current contacts with a rated current of 16 A at 63 V, allowing for reliable current transmission. It is suitable for supplying power to fieldbus components, power supply units, industrial machines, and motors, particularly in scenarios requiring high current and low voltage.

Technical data:

• Connections: 1 x M12 plug 5 pin L-coded, 1 x M12 socket 5 pin L-coded
• Copper cable
• Shielded
• Wire cross-section: 14 AWG (2.5 mm²)
• Rated current: 16 A / 63 V
• Width across flats: SW13
• Cable diameter: approximately 10.4 mm
• Cable sheath material: PUR
• Suitable for drag chains
• Drag chain speed: up to a maximum of 5 m/s
• Tightening torque: 0.6 Nm
• Bending radius (fixed): 5 x outer diameter
• Bending radius (movable): 10 x outer diameter
• Maximum number of bending cycles: 5,000,000
• Maximum number of torsion cycles: 500,000
• Torsional stress: ± 180 °/m
• Operating temperature (fixed): -40 °C to 80 °C
• Operating temperature (movable): -25 °C to 75 °C
• Flammability class: UL94HB
• Halogen-free, silicone-free, oil-resistant
• Protection class: IP66 / IP67
• Thread material: die-cast zinc
• Colour: grey
• Length including connections: approximately 2 m

Package contents:

• M12 cable

Packaging:

• Resealable bag.
