The motorised security lock is designed for situations where the benefits of motor-powered unlocking must be combined with the mechanical security requirements of lock models 309X and 409X. The integrated monitoring contacts ensure functionality. The bolt is retracted by an electric motor and pre-tensioned by a spring mechanism. When the door is closed, the control latch ensures that the pre-tensioned bolt is fully extended and the double action latch is blocked, which enhances the overall security level.

The lock operates on a fail-unlocked principle, remaining locked during a power failure and can only be opened with a key or by using the internal door handle. It features a mechanical automatic locking system with a double action lock, making it suitable for both DIN left-hand and right-hand doors. The mechanical self-locking process controls the interaction between the double action lock and the control latch.

This lock is burglary-resistant due to a solid bolt with a 20 mm throw, and it can achieve burglary resistance up to class 2 in appropriate door systems. It includes a panic function with approvals in accordance with EN 179 and EN 1125, and it is suitable for fire doors. The motorised unlocking feature makes it ideal for integration with door automation systems.

It is compatible with front door furniture and includes a changeover function for unlocking with a key from the outside. The monitoring functions are included, and the package contains one security lock and one operating manual. The locks in the model series 509X have a continuous follower and therefore require front door furniture (internal handle or panic bar, external knob or bar). The lock can be actuated by a card reader, code lock, timer switch, button, etc., and is suitable for standard doors.
