Properties

• Approved by building authorities

• Variable M10 or M12 threaded rod connection

• The only approved spacer fixing with M10 threaded connection used as standard, e.g., for French balconies

• Up to 250% more power than competitor products

• Suitable for thick insulation layers and spacer mounts up to 300 mm

• Reliable protection against rust, energy loss, and thermal bridges thanks to A4 stainless steel

Description & area of application

• Heavy-duty spacer fastening for insulation, clinker, and flat roofs

• Virtually no energy loss and no thermal bridges thanks to A4 stainless steel

• Building authority approval for all spacer mounts

• Quick and easy installation

• For insulation up to 220 mm

Processing & installation

• Drill through thermal insulation (Ø 30 mm)

• Measure the thermal insulation

• Drill hole in the building material and remove plaster layer if necessary

• Clean the drill hole

• Shorten threaded rods if necessary (length = drill hole depth + insulation layer) and screw on Iso Spacer

• In perforated brick, only use with a perforated sleeve. Insert this completely into the drill hole

• Fill 2/3 of the drill hole in the substrate or completely fill the perforated sleeve with composite mortar

• Insert the threaded rod with pre-assembled Iso Spacer into the drill hole with a slight twisting motion

• Allow the composite mortar to harden

• Seal the gap with silicone

• Mount the add-on part.
